600W LED Flood Light
OAK LED 600W LED Flood Light directly replace 1500-2000w metal halide.
5-10 times brighter than conventional led lamps.
Premium Precise Optical Lighting System.
95% high efficiency Low flicker rate less than 0.2%, special design for stadium HDTV
OAK-FL-Smart-600W
High Tech innovative thermal system design in 600W led flood light.
For led sports high power lighting, 30% electrical energy of led stadium light is converted into light energy, the rest is converted into heat energy, so thermal system is very important for the lifetime of led chip, drivers and the whole fixture.
In order to transfer so much heat energy fastest, Thermal System we designed with 30% higher heat dissipation efficiency comparing with convention led lamps.
Precise optical design of OAK LED fixture create Highest and Maximum Ground Efficiency, 30% more light can reach ground comparing with conventional led lamps.
| MN | Power (W) |
Size (mm) |
Efficiency |
Beam Angle |
Color |
Dimming |
| OAK-FL-100W-Smart | 100 | 318x255x70 | 170lm/w |
15, 25, 40, |
2700-6500K |
PWM |
| OAK-FL-150W-Smart | 150 | 318x320x70 | ||||
| OAK-FL-200W-Smart | 200 | 418x320x70 | ||||
| OAK-FL-300W-Smart | 300 | 468x436x70 | ||||
| OAK-FL-400W-Smart | 400 | 568x436x70 | ||||
| OAK-FL-500W-Smart | 500 | 568x501x70 | ||||
| OAK-FL-600W-Smart | 600 | 568x566x70 | ||||
| OAK-FL-720W-Smart | 720 | 668x566x70 | ||||
| OAK-FL-800W-Smart | 800 | 668x631x70 | ||||
| OAK-FL-1000W-Smart | 1000 | 718x696x70 |
Parameters
|
Model No. |
OAK-FL-Smart-600W |
|
Light Source |
Cree COB |
|
Driver |
Meanwell |
|
Power |
600w |
|
Luminous Efficiency |
170 lm/W |
|
Luminous Flux |
102,000 lm |
|
Input Voltage |
90~305V AC |
|
Beam Angle |
15° /25° /40° /60° /90° /120°optional |
|
Color Temperature |
1700~10,000K |
|
CRI |
≥80 |
|
IP Rating |
IP67 |
|
Lifespan |
>100,000h |
|
Power Factor |
≥0.95 |
|
Power Efficiency |
≥93% |
|
Power Frequency |
50~60HZ |
|
Working Temp. |
-40 ~ +55°C |
|
MH reference Replacement |
1500-2000W |
Surface Treatment
Special cooling channel
make sure the heat transfer to the air in different directions
Project References
600W Led Flood Light Applications:
Gymnasium, Sports Stadium Lighting;
Building, Billboard Lighting;
Workshop, Factory Lighting;
Warehouse, Storage Lighting;
Yard, Square Lighting;
Road, Highway Lighting;
Station, Dock Lighting etc
